How To Bleed Oil Furnace: A Complete Step-by-Step Technical Guide
Bleeding an oil furnace involves purging trapped air bubbles from the fuel line, pump, and nozzle assembly to restore continuous oil delivery and proper combustion. This routine maintenance task requires standard hand tools, a clean catchment container, and a systematic approach to safely reset the burner pressure and re-establish a stable flame.
Pre-Operation & Equipment Checklist
Maintaining an efficient residential heating system requires strict adherence to safety protocols and the use of proper diagnostic tools. Before attempting to purge air from your heating unit, verify that you have all necessary supplies assembled near the burner chassis.
- Essential Gear, Tools, and Materials: 1/4-inch or 5/16-inch box wrench (or specialized burner socket wrench), flexible transparent plastic tubing, a small glass or metal catch container, clean shop rags, and a flashlight.
- Mandatory Prerequisite Knowledge: Familiarity with the emergency shut-off switch, the location of the oil burner fuel pump (typically a Suntec or Webster model), and the reset relay button on the primary control cad cell relay.
- Estimated Budget and Duration Benchmarks: DIY execution costs nothing if tools are on hand, while professional service calls range from one hundred fifty to three hundred dollars. The physical bleeding process takes approximately fifteen to thirty minutes.
Step-by-Step Oil Furnace Bleeding Procedure
Step 1: Secure the Power Supply and Locate the Bleeder Port
Locate the emergency power switch for the heating system—usually mounted at the top of the basement stairs or on the side of the furnace chassis—and switch it to the OFF position. Remove the outer casing or burner door if necessary to gain unobstructed access to the fuel pump, which is the mechanical component where the copper oil supply line enters the burner housing. Identify the bleeder valve, which resembles a small grease fitting or bleed screw located on the side or face of the pump body.
Warning: Never attempt to bleed an oil furnace while the burner is actively firing or while the primary control is calling for heat, as atomized oil under high pressure creates severe fire and explosion hazards.
Step 2: Attach the Collection Line and Position Your Container
Push one end of your flexible clear plastic tubing securely over the nipple of the bleeder valve, directing the opposite end down into your clean catch container to prevent fuel spillage onto the floor. Position your box wrench onto the hex head of the bleeder valve, ensuring a snug fit to prevent rounding off the soft brass fitting during loosening. Keep your shop rags immediately adjacent to catch any residual drips that escape the collection tube.
Step 3: Initiate the Call for Heat and Open the Valve
Turn the home thermostat up several degrees above current room temperature to signal the primary control that a heat cycle is required. Flip the emergency power switch back to the ON position and observe the burner sequence, listening for the motor to spin up and the ignition transformer to energize. Immediately after the motor begins spinning, turn the bleeder valve counterclockwise one-quarter to one-half turn using your wrench to open the internal passageway.
Pro-Tip: Watch the clear plastic tubing closely as the pump engages; you will see a frothy mixture of air bubbles, foam, and dark heating oil rush through the line before a solid, bubble-free stream emerges.
Step 4: Purge Trapped Air Until Solid Fuel Flows
Allow the foamy air-oil mixture to vent continuously into your catch container until the stream becomes entirely solid, dark, and free of sputtering or intermittent air pockets. This process typically takes between fifteen to forty-five seconds depending on the volume of air trapped within the supply line and filter canister.
Step 5: Tighten the Bleeder Valve and Verify Burner Ignition
Rotate the bleeder valve clockwise until firmly snug, ensuring zero leakage past the tapered seat, then remove your clear plastic tubing. Within a few seconds of closing the valve, the oil burner should ignite its flame, establishing a steady, roaring combustion cycle tracked by the cad cell safety eye. If the burner locks out on safety—signified by a glowing red light on the primary control relay—wait sixty seconds, press the reset button once, and observe for normal operation.
How Do You Bleed A Radiator In A House | Gas Furnace
Oil Furnace Component Specifications and Operational Thresholds
| Burner Component | Typical Operating Parameter | Maintenance / Failure Threshold |
|---|---|---|
| Fuel Pump Pressure | 100 to 140 PSI (pounds per square inch) | Below 90 PSI causes atomization failure and soot. |
| Bleeder Valve Thread | 1/4-inch or 3/8-inch standard tapered pipe | Stripped threads require immediate pump replacement. |
| Cad Cell Resistance | Less than 1,600 ohms during active flame | Above 1,600 ohms triggers safety lockout. |
| Nozzle Spray Angle | 45, 60, or 80-degree hollow/solid cone | Wear after 1 year causes irregular burn patterns. |
Troubleshooting Persistent Air Lock and Burner Lockouts
Even after performing a standard bleed procedure, heating systems may experience intermittent lockouts or fail to sustain combustion due to underlying mechanical issues. Review these field diagnostics to resolve persistent heating failures.
- Root Cause: Continuous air ingestion through loose supply line fittings or a failing tank check valve.
- Actional Fix: Inspect all flare fittings between the oil storage tank and the burner pump, tightening any loose connections and replacing degraded gaskets or copper lines that show signs of weeping.
- Root Cause: Severely clogged fuel filter restricting oil volume and starving the pump of prime.
- Actional Fix: Shut off the oil supply valve at the tank, unscrew the fuel filter canister, replace the internal felt or micron cartridge element, and re-prime the system.
- Root Cause: Defective primary control relay or fouled cad cell eye preventing flame sensing.
- Actional Fix: Wipe the glass face of the cad cell eye clean with a soft rag, and test the primary relay voltage; replace components that fail electrical continuity tests.
Frequently Asked Questions
How many times can I press the reset button on my oil furnace?
You should press the burner reset button a maximum of one to two times. Repeatedly resetting a locked-out furnace without diagnosing the root cause can flood the combustion chamber with unburned heating oil, creating a severe explosion risk upon subsequent ignition attempts.
What causes an oil furnace to keep getting air in the lines?
Air typically enters the fuel supply line through loose mechanical fittings, cracked underground or aboveground copper lines, a faulty tank shut-off valve, or a dangerously low fuel level in your storage tank. Additionally, a restricted fuel filter can cause the pump to draw a high vacuum, pulling air past pump seal assemblies.
Do I need to bleed my oil furnace after running out of oil?
Yes, running out of oil forces the entire supply line and fuel pump cavity to fill with air. Whenever the tank runs dry and is subsequently refilled, you must manually bleed the pump using the bleeder valve to restore solid fuel pressure before the burner can successfully light.
Can I use a standard wrench to bleed my oil burner pump?
Yes, standard open-end or box wrenches work well, but you must ensure the sizing is exact to prevent rounding the brass bleeder fitting. Metric and SAE sizing variations exist depending on whether your burner utilizes an American or European pump manufacturer.
Professional Heating Maintenance and Support
Ensuring your heating system operates safely and at peak seasonal efficiency requires periodic comprehensive tunings and combustion efficiency testing by licensed technicians. Schedule an annual professional service to clean heat exchangers, replace fuel nozzles, and test safety controls before the winter heating season begins.
